6000PSI Straight Needle Valve Hydraulic Flow 1/4″ NPT Female Valve Precision
USD 27.90 USD
Specifications
| Thread Size | 1/4" NPT |
| Valve Operation | Manual |
| Model | J13W-6000PSI |
| Material | 316 Stainless Steel |
| Color | Silver |
| Process | CNC Machining |
| Style | Needle Valve |
| Mounting | Threaded Connection |
| Applicable Hose | Metal Hose |
| Applicable Temperature | ≤150℃/302℉ |
| Maximum Working Pressure | 6000PSI |
| Gross Weight | 0.4kg/ 0.88 lbs |
| Valve Body Size (L*H) | 5.5*2.8cm/2.17*1.1in |
| Valve Body Interface Diameter | 1.15cm/0.45in |
| Handle Size (L*φ) | 6*1.2cm/2.36*0.47in |
| Type | Needle Valve |
| Features | High Precision |
| Item Diameter | 5.5*2.8cm/2.17*1.1in |
| Finish | CNC Machining |
Specification Model: J13W-6000PSI Material: 316 Stainless Steel Color: Silver Process: CNC Machining Assembly Required: No Style: Needle Valve Mounting: Threaded Connection Thread Size: 1/4" NPT，1/2" NPT Applicable Hose: Metal Hose Number of Ports: 2 Applicable Temperature: ≤150℃/302℉ Operating Temperature: -20~150℃ /-4~302℉ Applicable Media: Hydraulic, Water, Oil and Gas Maximum Working Pressure: 6000PSI Flow Diameter: Φ6 Gross Weight: 0.4kg/ 0.88 lbs Package Size: 9*6*3 cm/3.54*2.36*0.1 in Valve Body Size (L*H): 5.5*2.8cm/2.17*1.1in Valve Body Interface Diameter:1.15cm/0.45in Handle Size (L*φ): 6*1.2cm/2.36*0.47in Handle Distance from Valve Body: 6.3cm/2.48in Package Included 1 * 316 Stainless Steel Straight Needle Valve.
